Netafim Techline EZ Dripline

Techline™ EZ

Ideal for small and medium areas, Techline™ EZ offer one coil, two fittings and less than one-hour installation. It's the simplest solution for small sites. Netafim's Techline™ EZ is the 12mm dripline for on-surface looped systems that installs fast, saves water and "disappears" into the landscape.

---

Why Techline™ EZ?

The first anti-siphon emitter in Landscape dripline, successfully used in harsh agricultural applications before its introduction into Landscape. The emitter is pressure compensating and continuous flushing, the anti-siphon feature prevents ingestion of debris into the tubing caused by vacuum.

• Laser Etched, For Easy Identification
• Made With Post-Consumer Recycled Material
• Qualifies for Use on Leed Projects
• UV Resistant Tubing
• Self-Contained, One-Piece Dripline Construction

---

Product Advantages

• Less Visually Obtrusive
  12mm diameter tubing is less noticeable in landscape installations.
• Self-Contained, One-Piece Dripline Construction
  Assures reliable, easy installation.
• Flexible UV Resistant Tubing
  Adapts to any planting area shape – tubing curves at a 6″ radius. On-surface installations withstand heat and direct sun.
• More Cost-Effective in Smaller Bed Areas
  24% smaller diameter tubing.

---

Applications

• Subsurface or on-surface installations
• Bed areas that require shorter lateral lengths
• Areas subject to vandalism
• Planting areas
• Curved, narrow, and angular planting areas
• Flower beds, trees, and shrubs
• Rooftop gardens
• Vegetable gardens
• Green walls
• High traffic or high liability areas
• Raised planters

---

Specifications

• Emitter flow rates: 0.26, 0.4, 0.6 and 0.9 GPH
• Emitter spacings: 6″, 12″, and 18″
  (6″ available for 0.26 and 0.4 GPH only)
• Uses 12mm Netafim Insert Fittings or any compression fitting for 0.426″ diameter tubing
• Pressure compensation range: 6 to 58 psi
• Bending radius: 6″
• Maximum system pressure: 58 psi
• Minimum pressure required: 6 psi
• Tubing diameter: .510″ O.D.; .426″ I.D.
• Coil length: 200′, 250′, 300′, 500′, 1,000′
• Recommended minimum filtration: 120 mesh
• Diaphragm made of silicon′
• ISO 9261 Standard Compliance
